Ringlock Horizontal Ledger
• Two wedge-shaped heads with self-locking function, quickly assembled and disassembled, ensuring safety and efficiency,
• Made of high-strength steel, hot-dip galvanizing on inner and outer surfaces to prevent corrosion in harsh environments.
• Tube body forms circular or rectangular according to different load bearing requirements.
• The tube body length can be customized.
Product details
As key components of ringlock scaffolding, horizontal ledgers play core role in structural stability and load transmission that are usually made of Q355B low alloy high strength structural steel, on the two heads of which are welded with wedge-shaped cast steel joints and a pin inside of each. When joined, the pins are inserted into the cavities of the connector on the vertical standard, forming stable rigid nodes. The shear bearing capacity of each node can reach more than 10kN, ensuring the uniform transmission of horizontal stress.
Specs (mm) | Body Length (mm) | Tube Length (mm) | Weight （kg) |
390 | 390 | 341 | 2.23 |
730 | 732 | 683 | 3.42 |
1090 | 1088 | 1039 | 4.68 |
1570 | 1572 | 1523 | 6.41 |
2070 | 2072 | 2023 | 8.19 |
2570 | 2572 | 2523 | 9.97 |
3070 | 3072 | 3023 | 11.75 |
